Overall dimension(L*W*H)MM

6560*3100*3450

Working width(MM)

2900

Working efficiency(HA.)

0.67-1.33

Height of stubble(MM)

≤150

Straw length(theoretical)(MM)

9-22mm stepless adjustable

Feeding quantity

14kg/s

Structure weight(KG)

8800

The min.passing radius  turning left(MM)

7500

The min.passing radius  turning right(MM)

7600

Wheel distance  guiding pulley(MM)

1580

Wheel distance  driving wheel (MM)

2250

The standard of tyre (driving tyre)

15-24(∅1330x410mm)

Air pressure

0.18-0.2MPa

Wheel base

2300mm

The Min. ground clearance

240mm

The type of the cab

Normal

The lowest stubble height

≤150

The range of header’s lifting

120-830mm

Feeding quantity

14kg/s

The type of the cutting straw

Drum-type

The diameter of the rotor

630mm

The turning speed of the main axle

1200 r/min

Throwing height

5350mm

Throwing distance

>8 m

The throwing drum’s rotation angle

270 degree

Working speed

0-20km/h. stepless speed change

The quantity of hay cutter’s blades

48 pcs
